Product parameters
| 型号 | Model | NCMF-2-400 | NCMF-2-600 | NCMF-2-800 | NCMF-2-1000 |
| 材料宽度(mm) | Material width | 50-400 | 50-600 | 70-800 | 70-1000 |
| 材料厚度(mm) | Material thickness | 0.3-4.5 | 0.3-4.5 | 0.3-4.5 | 0.3-4.5 |
| 卷材重量(kg) | Coil weight Max. | 3000/5000 | 3000/5000 | 5000/7000 | 7000 |
| 卷材外径(mm) | Coil O.D. Max | 1400 | 1400 | 1400 | 1400 |
| 卷材内径(mm) | Coil I.D. | 480-520 |
480-520 | 480-520 | 480-520 |
| 最大送料长度(mm) | Feed length 1* | 500 | 500 | 500 | 500 |
| 生产速度（m/min) | Feed speed | 24 | 24 | 24 | 24 |
| 工作滚轮(支） | Work roller(pc) 2* | 上4/下3 Up4/Down3 | 上4/下3 Up4/Down3 | 上4/下3 Up4/Down3 | 上4/下3 Up4/Down3 |
| 送料滚轮（组） | Feed roller(set) | 1 | 1 | 1 | 1 |
| 主电机(KW) | Main motor | AC3.0 | AC4.4 | AC7.5 | AC7.5 |
| 扩充方式 | Coil expansion | 液压Hydraulic | 液压Hydraulic | 液压Hydraulic | 液压Hydraulic |
| 料架电机(KW) | Decoil motor | 1.5/2.2 | 1.5/2.2 | 2.5/3.7 | 3.7 |
| 电源(V) | Power supply | 380/200 | 380/200 | 380/200 | 380/200 |
| 空气压力(Mpa) | Operating air | 0.49 | 0.49 | 0.49 | 0.49 |
| 机械重量(kg) | Machine weight | 6000 | 6300 | 6600 | 7000 |
| 机械长*宽*高(m) | Dimension A*B*C | 4*1.8*2.6 | 4*2*2.6 | 4*2.2*2.6 | 4.2*2.5*2.6 |
| 备注： | |||||
| 1*：送料长度超过标准规格时，需要交替运转切换。 | |||||
| When the feeding length exceeds the standard, it needs to switch alternately | |||||
| 2*：校正辊轮数量可按客户要求定制。 | |||||
| The number of adjust roller can be customized according to customer requirements | |||||
